CAMERA BÁO KHÓI WISUALARM SAV849HA-E
Mô tả sản phẩm
THÔNG TIN SẢN PHẨM
– Thiết bị có độ nhay cao, độ ổn định cao.– Kiểu dáng đơn giản, dễ lắp đặt.– Bảo vệ khu vực rộng 30 – 60m2.– Thiết bị sẽ gửi tín hiệu bằng hình ảnh và âm thanh để cánh báo đến người dùng khi xảy ra sự cố.– Dùng nguồn DC 12V, hệ PAL.– Âm lượng báo động hơn 85dB.– Đầu báo sẽ tự phân loại báo động: khói, lỗi kỹ thuật…để không gây nhầm lẫn cho người dùng.
THÔNG SỐ KỸ THUẬT
|
Model |
DHI-HY-SAV849HA-E |
|
Communication |
1 RJ-45 PoE 10M/100M Ethernet ports |
|
Indicators |
Standby: Green indicator flashes once per minute Fault: Red indicator flashes once per minute Alarm: Red indicator flashes once per second Self-testing: Red indicator flashes once per second |
|
Protection Area |
30 m2–60 m2 |
|
Operating Principle |
Photoelectric |
|
Alarm Method |
Sound and LED Indicator |
|
Power |
DC12V / PoE and 3V lithium battery |
|
Operating Current |
≤30uA (Camera excluded) ≤300mA (Camera included) |
|
Back-up Battery Life |
＞ 3 years |
|
Alarm Classification |
Smoke alarm, fault warning, undervoltage alarm |
|
Alarm Sound Pressure |
≥85 dB (A) @ 3 m (9.84 ft) |
|
Product Dimensions |
Φ120 mm×79 mm (Φ4.72″ × 3.11″ ) |
|
Package Dimensions |
164 mm × 153 mm × 111 mm (6.46″ × 6.02″ × 4.37″)(L × W × H) |
|
Installation |
Ceiling mount |
|
Network Camera |
|
|
Image Sensor |
1/2.7″ CMOS |
|
Focal Length |
2.0 mm |
|
Field of View |
Horizontal: 144°; Vertical: 92°; Diagonal: 179.6° |
|
Max. Resolution |
5 MP |
|
ROM |
256 MB |
|
RAM |
512MB |
|
Day/Night |
Auto (ICR) |
|
Noise Reduction |
3D NR |
|
WDR |
True WDR |
|
S/N Ratio |
＞56 dB |
|
AGC |
Auto; manual |
|
White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
|
BLC |
Yes |
|
HLC |
Yes |
|
Compression |
H.265; H.264; H.264H; H.264B |
|
Video Bit Rate |
H.264: 32 Kbps–10240 Kbps H.265: 12 Kbps–7168 Kbps |
|
Frame Rate |
50Hz: Main stream (2688 × 1520@25 fps/2688 × 1520@25 fps/2304 × 1296@25 fps) Sub stream (704 × 576@25 fps/(704 × 576@25 fps/(704 × 576@25 fps) Third stream(704 × 576@25 fps/1920 × 1080@14 fps/1920 × 1080@25 fps) 60Hz: Main stream (2688 × 1520@30 fps/2688 × 1520@30 fps/1280 × 720@30 fps/1920 × 1080@30 fps) Sub stream (704 × 480@30 fps/704 × 480@30 fps/704 × 480@30 fps) Third stream (1920 × 1080@25 fps/704 × 480@30 fps/1920 × 1080@30 fps) |
|
L:W |
16:9 |
|
Max. Frame Rate |
2592 × 1944@20fps |
|
Bit Rate Control |
Variable/Constant |
|
Default Frame Rate |
4096 Kbps (2592 × 1944) |
|
Language |
English |
|
Alarm Linkage |
Smoke Alarm |
|
Special |
Auto WDR at night |
|
Image Setting |
Brightness; contrast; sharpness; saturation; gamma |
|
OSD |
Channel/time/place/voltage of back-up battery |
|
Image rotation, mirroring, flipping |
Yes |
|
Recording Mode |
Recording manually or linked with alarm |
|
Storage |
Imou; FTP; SFTP; Micro SD card (256G); NAS |
|
Network |
RJ-45 (10/100 Base-T) |
|
User |
10 channels at most |
|
Reset |
Yes |
|
Browser |
IE7 and newer versions; Chrome 8+; Firefox 3.5+; Safari 5+ |
|
Alarm Input Interface |
2 channels In: 5mA 5VDC |
|
Alarm Output Interface |
2 channels Out: 300mA 12VDC |
|
Security |
Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1X; controlled network access |
|
Protocol |
HTTP;TCP;RTSP;RTP;UDP;RTCP;SMTP;FTP;DHCP;DNS;DDNS;IPv4/v6;SNMP;QoS;UPnP;NTP |
|
Interoperability |
ONVIF; MileStone; Genetec; CGI; PISA |
|
Power Supply |
DC12V+PoE |
